B Type Hose Tail - Stainless Steel
Item #: AK100HE-S
Your Price:
$44.10
/
each
ea
Listed Price:
$44.10
/
each
ea
Product Overview
Millennium Coupling Company’s Stainless Steel Universal B Type Claw Coupling with integrated multi-barbed hose tail is engineered for fast, secure, and leak-free connections in pneumatic systems. Designed to fully interchange with the U.S. Military Specification CID A-A-59553, these two-lug couplings are ideal for compressed air and water transfer in corrosive industrial environments.
Whether you're working in oil & gas, mining, construction, agriculture, or manufacturing, our claw couplings deliver unmatched reliability, safety, and compatibility.
Key Features
• Universal Compatibility: Fully interchangeable with other couplings conforming to CID A-A-59553 and the superseded WW-C-633D standard.
• Quick Connect/Disconnect: Quarter-turn twist-lock mechanism ensures rapid and secure hose connections.
• Robust Construction: Manufactured from investment cast stainless steel for improved corrosion resistance.
• Leak-Free Seal: Precision-machined seal area with nitrile rubber or optional FKM seals for enhanced chemical resistance.
• Safety Locking Pin: Optional locking pin prevents accidental disconnection in high-vibration environments.
Specifications
Standard - Interchangeable with CID A-A-59553 (Replaces WW-C-633D)
Material - Stainless Steel 316 (ASTM A 743 CF-8M)
Seal Material - Nitrile Rubber (NBR)
Working Pressure - 150 psi (1.03 MPa)
Burst Pressure - 600 psi (4.14 MPa)
Temperature Range - -35°C to +120°C (-30°F to +250°F)
Claw Distance - 42 mm (Universal fit)
Applications
• Commonly used in Oil & Gas Market for air services
• Chemical processing plants
