Simple, Economical, Trusted - Tellusloc™ Ground Anchoring Solutions


Earth Anchors

Tellusloc™ Anchors are designed for use with geotextiles but have various other applications. They remove the need for digging and earth moving. They are driven into the ground to the desired depth using a hammer or a post driver. This creates minimum soil disturbance. The anchor heads are engineered and tested to work with a variety of soil types.

logo
Road
How it works
The anchor locks into place by being pulled upward at force against the earth above it. The wing area provides a large cross sectional area to allow an increased loading capacity.
l

Typical Anchor Behaviour

The easy installation keeps the labour cost down while providing structural integrity to the soil and the geotextile. The aluminium anchor has a 30 year service life providing long term solutions while remaining cost effective as well as light weight. The plate design provides a maximum grip to the fabric, while the circumferential wedge grip ensures that the plate stays fixed to the fabric.

Applications
4
3
2
Tellusloc
Part No A1
Part No A2
Part No A3
A1A2A3
Anchor Head Material
Aluminium
Aluminium
Aluminium
L x W x H (cm)
9.5 x 4.5 x 2.6
14.4 x 7.0 x 4.3
18.3 x 9.0 x 5.7
Impact Strength (kN)
58.0
109.9
164.0
Impact Fatigue
> 12,000 cycles
> 12,000 cycles
> 12,000 cycles
Cable Material
Galvanised Steel
Galvanised Steel
Galvanised Steel
Wire Diameter (mm)
3.2
4.8
4.8
Strength (kN)
9.3
16.5
16.5
Lower Termination
Aluminium Ferrule
Aluminium Ferrule
Aluminium Ferrule
Top Plate Diameter (cm)
11.5
16.5
16.5
Anchor Plate Material
Aluminium
Aluminium
Aluminium
Top Termination
Circumferential Wedge Grip
Circumferential Wedge Grip
Circumferential Wedge Grip
